Huawei AP6010DN-AGN Hardware Installation And Maintenance Manual

1 Indoor AP Overview
1.1 Device Structure
Figures in Table 1-1 show the appearance of indoor APs.
CAUTION
There is a scald warning label attached on the device, warning you not to touch the device after
the device has been operating for a long time.
Table 1-1 Appearance of indoor APs
Product Model Appearance
AP3010DN-AGN
AP5010DN-AGN
AP5010SN-GN
AP6010DN-AGN
AP6010SN-GN
1
2
3
6
7
ConsoleETH/PoEDefaultDC 12V
Huawei AP3x10xN&5x10xN&5x30xN&6x10xN&7x10xN
Hardware Installation and Maintenance Guide 1 Indoor AP Overview
Issue 11 (2015-05-18) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
