Scenario II : Mounting the NE05E on a Wall
a
b
Install the multi-functional accessory
c
Install the NE05E
1. Fix the mounting bracket on the back of the device on the multi-functional accessory from the top down.
2. Fasten the screw.
3±0.2 N·M
M6
Mark the installation position for the
multi-functional accessory on the wall
Drill holes in the marked diagonal position
Install the diagonal expansion bolt in pairs
Flat washer
Expansion
tube
Bolt
Remove the nut and flat washer, and install the
multi-functional accessory
Use level to
mark dots
horizontally.
Ø8 drill bit
Nut
