LTE CPE B2368 User's
Guide 13 L2TP VPN
Issue 01 Copyright © Huawei Technologies Co., Ltd. 96
Item Description
Username The user or group of users authorized L2TP VPN tunnel
use.
Password User password.
Use
Click this button to save your changes settings LTE modem.
back
Click this button to return to the previous screen without saving.
13.3 Screen Monitor
This screen allows you to monitor the status of the L2TP VPN tunnel. The following screen, click on Security> This screen allows you to monitor the status of the L2TP VPN tunnel. The following screen, click on Security>
L2TP VPN> Monitor.
Figure 13-3 Security> L2TP VPN> Monitor Figure 13-3 Security> L2TP VPN> Monitor
The following table summarizes the available fields on this screen.
Table 13-3 Security> L2TP VPN> Monitor Table 13-3 Security> L2TP VPN> Monitor
Item Description
#
This is the serial number of rules. Check the box to activate the rule.
State An icon indicating the L2TP VPN tunnel.
name of tunnel Name of the tunnel.
IP address of
the server
In this field the IP address of the remote gateway.
L2TP Server IP
Address
In this field the IP address that LTE modem is assigned to a remote computer
connected via L2TP VPN tunnel.
Local L2TP IP
address
In this field the IP address of the computer connected to the LTE modem via L2TP
VPN tunnel.
Current status Text description of the current state of the connection to the L2TP VPN tunnel.
