Installation
3
100 meters (328 feet). To achieve better effect, use
the shielded cable.
◆ Step 4: Connect to a telephone set
The communication quality of the telephone set can
be interfered by the wireless signal. Place the
telephone set one meter away from the device.
◆ Step 5: Place the device
The gateway can be placed horizontally on a table,
hanging against the wall, or leaning against the
pedestal. Place the gateway on a higher place or
near the window, so it can receive stronger signals.
Press the bayonet of the pedestal, and place the
gateway into the pedestal as shown in the figure.
Thus, the gateway can lean against the pedestal.
!
Warning
To avoid electrical devices from interfering by
the wireless signal, place electrical devices one
meter away from the gateway.
◆ Step 6: Connect the external antenna (optional)
Connect the external antenna cable with the antenna
jack on the main unit. Screw the cable to make sure
