Huawei Baudcom EG8145V5 User Manual

4 Technical Specications
Product Function
EG8145V5 ● 4 Ethernet ports
● 1 POTS port
● 1 USB port
● 2.4 GHz & 5 GHz Wi-Fi
● Power adapter input: See the nameplate on the adapter.
● System power supply: See the nameplate on the device.
● Ambient temperature: 0ºC to +40ºC
● Ambient humidity: 5%–95% (non-condensing)
● Dimensions (H x W x D): 30 mm x 173 mm x 120 mm (without external
antenna and pads)
● Weight: About 250g
● Maximum system power consumption: 18 W
EG8145V5
Quick Start 4 Technical Specications
Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd. 7

Huawei Baudcom EG8145V5 Specifications

General

Model	EG8145V5
GPON Port	1
Antenna Gain	5 dBi
Operating Temperature	0°C to 40°C
Ethernet Ports	4 x GE
Wi-Fi	802.11 b/g/n/ac
USB Port	1 x USB 2.0
Power Supply	12V DC
Dimensions	176 x 138 x 28 mm
Operating Humidity	5% to 95% RH (non-condensing)
Antennas	2 x external antennas
