Huawei EchoLife HG510 HOME GATEWAY

User Manual
EchoLife HG510 Home Gateway Chapter 3 Configuration Guide
Huawei Technologies Proprietary
3-26
VI.
WAN Setup – Summery
The last page gives a summary of previous steps. Make sure that
the settings match the settings provided by ISPS, and then
Click<Save/Reboot> to complete the configuration procedure. Refer
to “3.3.2 VI. WAN Setup – Summary”.
3.3.5 Configuring PPPoA
Click<Quick Setup> in the left frame, and follow the steps below
to create a PPPoA connection. The following setting steps are all the
same as PPPoE steps.
Follow the steps listed below to configure.
Stage Description See in
1 Configure ATM PVC I.
2 Select Connection type II.
3 Configure PPP username and password III.
4 Enable IGMP Multicast and WAN service IV.
5 Configure LAN Service V.
6 WAN setup-summary VI.
I.
Configure ATM PVC
Enter the VPI/VCI values.
Refer to “3.3.1 I. Configure ATM PVC”.
