Chapter 2 Installation
2.1 Connecting Cables
You need to connect HG550 with the phone jack on the wall, your
computer(s), and the power adapter.
Caution:
Before operation, you need to power off your computer(s), LAN
hub/switch, and HG550.
I. Connect the ADSL line
Use a telephone line to connect the ADSL interface of HG550
with either of the following two interfaces:
the phone jack on the wall
the Modem interface of a splitter
II. Connect the network cable
To connect HG550 to a LAN or computer, do as follows:
Use a network cable to connect the hub port or the Ethernet
interface of your computer with a LAN interface of HG550.
