EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
1 Introduction
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
LEDs
Figure 1-16 LEDs on the HG8240A
Table 1-16 Indications of the LEDs on the HG8240A
LED
Description
Status
Description
POWER
Power supply
LED
Green: always
on
The device is powered on.
Orange: always
on
The power supply is cut off.
PON
Authentication
LED
See Table 1-17.
LOS
Connection
LED
See Table 1-17.
LAN1–LAN4
Ethernet port
LED
Always on
The Ethernet connection is in the
normal state.
Blinks
Data is being transmitted on the
Ethernet port.
Off
The Ethernet connection is not set
up.
