Huawei EchoLife HG8045A User Manual

EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
1 Introduction
Issue 01 (2013-08-08)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
Figure 1-14 Ports and buttons on the side cover of the HG8240A
Table 1-14 Description of ports and buttons on the side cover of the HG8240A
Port/Button
Function
Reset
Indicates the reset button. Press the button for a short time to
reset the device; press the button for a long time (longer than
10s) to restore the device to the default settings and reset the
device.
Figure 1-15 shows optical ports on the HG8240A.
Figure 1-15 Optical ports on the HG8240A
Table 1-15 Description of optical ports on the HG8240A
Port/Button
Function
OPTICAL
Indicates an optical port. The optical port is equipped with a
rubber plug and is connected to an optical fiber for upstream
transmission.
The type of the optical connector connected to the OPTICAL
port is SC/APC.

Huawei EchoLife HG8045A Specifications

General

Brand	Huawei
Model	EchoLife HG8045A
Category	Network Router
Language	English
