LEDs
Figure 1-6 LEDs on the HG8240H
Table 1-4 Indications of the LEDs on the HG8240H
LED
Description Status Description
POWER
Power supply
LED
Always on The device is powered on.
Off The power supply is cut off.
PON
Authentication
LED
See Table 1-5.
LOS
Connection
LED
See Table 1-5.
LAN1–LAN4
Ethernet port
LED
Always on
The Ethernet connection is in the
normal state.
Blinking
Data is being transmitted on the
Ethernet port.
Off
The Ethernet connection is not set
up.
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
