Huawei EchoLife HG8245 Product Description

EchoLife HG8245 GPON Terminal
Product Description 3 Technical Specifications
3 Technical Specifications
3.1 Optical Port Specifications
GPON Port Specifications
Table 3-1 GPON port specifications
Parameter
Specifications
Transmission rate
Rx: 2.488 Gbit/s
Tx: 1.244 Gbit/s
Port mode
Single mode
Connector
SC/APC
Maximum reach
20 km
Standard compliance
ITU-T G.984.2 CLASS B+
Center wavelength
Tx: 1310 nm
Rx: 1490 nm
Tx optical power
0.5 dBm to 5.0 dBm
Extinction ratio
> 10 dB
Maximum receiver sensitivity
-27 dBm
Maximum overload optical power
-8 dBm
3.2 Power Specifications
 Power adapter input: 100–240 V AC, 50–60 Hz
Issue 01 (2011-01-18) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3-1
