EchoLife
HG8245A/HG8245H/HG8240A/HG8045A/HG8247H
Gateway ONT
Product Description
1 Introduction
Issue 02 (2013-09-27)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
Figure 1-9 Ports and buttons on the side cover of the HG8245H
Table 1-8 Description of ports and buttons on the side cover of the HG8245H
Port/Button
Function
Reset
Indicates the reset button. Press the button for a short time to
reset the device; press the button for a long time (longer than
10s) to restore the device to the default settings and reset the
device.
WLAN
Indicates the WLAN button, used to enable or disable the
WLAN function.
WPS
Indicates the WLAN protected setup.
Figure 1-10 shows optical ports on the HG8245H.
Figure 1-10 Optical ports on the HG8245H
