3
Installation Precautions
Attaching Labels/Tags
Attach a label or tag to the signal cable 20 mm (0.79 in.) away from the connector. When the cable is placed
vertically, the label or tag should point to the right. When the cable is placed horizontally, the label or tag
should point downwards. After routing a cable, make a label or tag and then attach it to the cable for the ease-
of-maintenance.
Binding the cables
Cut off the remaining parts of the cable ties neatly using diagonal pliers to protect your fingers.
