5 Installing the Cabinet on an Underground Base
5.5 Installing the Cabinet on the Underground Base
• Construct the protection fence after installing the cabinet.
• Plan the coverage of the protection fence based on the ground plan to ensure that all doors of the cabinet can be opened
without difficulties.
• The accessories of a battery compartment include 3 types of spacers. These 3 types of spacers have different
thicknesses. Select a proper spacer based on the live-network environment so that the cabinet bottom is level.
F01T500 cabinet
Place the cabinet on the underground base.
Bearing capacity of the steel rope > 750kg
To Next Page
