3 Appearance and Structure
Cabinet structure (AC Power Supply)
Battery compartment
(Optional)
Internal-circulation Fan
Service device
Power system
Battery
Battery Heater
Cable distribution
compartment
ODF
CCU (or Fan monitoring box +
signal transferbox)
AC PDU
External-
Circulation fan
Meter installation position
Circuit breakers installation position
Power meter box
Cable aperture
Fuse interface
(Reserved)
