1.2 The Rear and Side Panel of the HG256
1.
The rear panel of the HG256 provides the following interfaces and button:
z
One WAN interface: WAN
z
One PHONE interface: PHONE
z
Four LAN interfaces: LAN1, LAN2, LAN3, LAN4
z
One Reset button: RESET
z
One power interface: POWER
2.
The side panel of the HG256 provides the following interface and buttons:
z
One USB interface: USB
z
One WPS button: WPS
z
One WLAN button: WLAN
z
One ON/OFF button: ON/OFF
2
