Huawei HG630 Product Description

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Page 12 of 16
3 Technical Specifications
3.1 Interface Features
3.1.1 DSL Interface
Multiple DSL Standards

VDSL2
− Supports G.993.2 VDSL2
− Supports VDSL2 Profiles for 8a, 8b, 8c, 8d, 12a, 17a
− Supports VDSL Vectoring

ADSL2+
− Supports G.992.5 (G.dmt.bitplus)

ADSL2
− Supports G.992.3 (G.dmt.bis) Annex L

ADSL
− Supports G.992.1 (G.dmt)
− Supports G.992.2 (G.lite)
− Supports G.994.1 (G.hs)
− Supports ANSI T1.413 Issue 2
Other Features

Supports multiple permanent virtual channels (PVCs)

Supports manual configuration of PVC parameters
3.1.2 WLAN Interface

Supports 802.11n 2×2 antenna

Supports 802.11b, 802.11g, 802.11n (2.4 GHz ~ 2.4835GHz)

Supports WPS 2.0 (PBC mode and PIN mode)

Supports DQPSK, DBPSK, CCK, OFDM, BPSK, QPSK, 16-QAM and 64-QAM
wireless modulation method

Huawei HG630 Specifications

General

Wi-Fi Standard	802.11b/g/n
Frequency Band	2.4 GHz
LAN Ports	4
WAN Port	1 x RJ-11
Wireless Speed	300 Mbps
WLAN	Yes
Firewall	Yes
Ports	4 x LAN, 1 x WAN, 1 x USB
Wi-Fi	Yes
VDSL2 Support	Yes
ADSL2+ Support	Yes
VoIP	No
Security	WPA/WPA2
LAN Port Type	Ethernet
Type	Wireless
Device Type	Wireless Router
