Please use the parameters provided by your internet service provider (ISP) for
configuration. If the configuration is wrong, you will not be able to access the
Internet.
Using the Embedded PPP Dial-Up Software of the
HG655b to Get Online
Step 1
Step 2
Configure the HG655b to enable the embedded dial-up function
1. Connect the HG655b with your computer by using the Ethernet cable.
2. Configure the IP address of your computer to be in the same network
segment as the HG655b. The default LAN IP address and subnet mask of
the HG655b is 192.168.1.1 and 255.255.255.0.
3. Start Internet Explorer on your computer and enter the http://192.168.1.1
in the address bar, and then press Enter.
4. The Login dialog box is displayed.
5. Enter the administrator name (admin by default) and password (admin
by default) in the Login dialog box, and then click OK.
Enable the embedded dial-up function
1. In the navigation tree on the left of the Web-based configuration utility,
choose Basic > WAN.
2. Click New.
3. Select Enable check box for WAN connection.
4. Select INTERNET from the Service list drop-down combo box.
5. Select Route from the Connection mode drop-down combo box.
6. Select PPPoE option button for Connection type.
7. Select Enable check box for NAT.
8. Enter the user name and password that are provided by the network
operator in the User name and Password text boxes, and keep the default
settings of other parameters.
9. Click Submit to save the settings.
After you complete the preceding settings, you can surf the Internet.
