Mounting a GPON Terminal On The Desk
The schematic diagram for placing the device on a desk horizontally is as
follows (The HG8240H5 is used as an example here.):
Mounting a GPON Terminal Onto The Wall
Step 1 Mark the positions of two holes used for mounting a GPON terminal,
ensure that the two holes have the same spacing as the two
mounting holes.
Step 2 Select a proper drill according to the outer diameter of the screws.
Use a hammer drill to drill the marked positions on the wall. Then
clean the wall and install two expansion bolts.
Step 3 Use a screwdriver to fasten the screws into the expansion bolts,
leaving the heads of the screws 3 mm over the wall. Then install the
GPON terminal to the screws.
