8
1. Configure the PC and iBOX to be in the same network
segment.
2. Use a straight-through cable to connect the PC to the DATA
port on the adapter.
3. Open Internet Explorer, choose Tools > Internet Options >
Advanced, and ensure that Use TLS 1.1 and Use TLS 1.2
are selected.
4. Enter https://iBOX IP address in the address box of Internet
Explorer to log in to the iBOX WebUI homepage.
Logging In to the iBOX WebUI and Setting Parameters
3.2
5. On the iBOX WebUI, Choose System Settings > Battery Curve.
6. On the Battery Curve page, select the battery string to be set, set Battery Brand and Format,
click Filter > Submit.
Default iBOX settings:
• IP address: 192.168.0.10
• Subnet mask:
255.255.255.0
• Gateway: 192.168.0.1
• User Name: admin
• Password: Changeme
* The figure uses the iBOX software version V296B019 as an example.
