Indoor Unit
Outdoor Unit
Refrigerant Charge Amount (L) (L is total one
-
way pipe length)(kg)
0 m < L
≤ 10 m
10 m < L ≤ 60 m
60 m < L ≤ 100 m
NetCol8000
-
A045D
NetCol500
-A060/
NetCol500
-A120 system 1/
NetCol500
-A120 system 2
9.4
9.4 + (L
– 10) x
0.21
9.4 + (L
– 10) x
0.28
NetCol500
-A080
13.4
13.4 + (L
– 10) x
0.21
13.4 + (L
– 10) x
0.28
NetCol8000
-
A045D including
a low
temperature
component
NetCol500
-A060/
NetCol500
-A120 system 1/
NetCol500
-A120 system 2
32.9
32.9 + (L
– 10) x
0.21
32.9 + (L
– 10) x
0.28
NetCol8000
-
A045U
NetCol500
-A060/
NetCol500
-A120 system 1/
NetCol500
-A120 system 2
8.8
8.8 + (L
– 10) x
0.21
8.8 + (L
– 10) x
0.28
NetCol500
-A080
12.8
12.8 + (L
– 10) x
0.21
12.8 + (L
– 10) x
0.28
NetCol500
-W055
9.6
9.6 + (L
– 10) x
0.19
-
NetCol8000
-
A045U
including
a low
temperature
component
NetCol500
-A060/
NetCol500
-A12 system 1/
NetCol500
-A120 system 2
32.3
32.3 + (L
– 10) x
0.21
32.3 + (L
– 10) x
0.28
NetCol8000
-
A090D
system 1
NetCol500
-A060/
NetCol500
-A120 system 1/
9.4
9.4 + (L
– 10) x
0.21
9.4 + (L
– 10) x
0.28
NetCol500
-A080
13.4
13.4 + (L
– 10) x
0.21
13.4 + (L
– 10) x
0.28
NetCol8000
-
A090D
system 2
NetCol500
-A060/
NetCol500
-A120 system 2
9.4
9.4 + (L
– 10) x
0.21
9.4 + (L
– 10) x
0.28
NetCol500
-A080
13.4
13.4 + (L
– 10) x
0.21
13.4 + (L
– 10) x
0.28
NetCol8000
-
A090D
system 1
including a low
temperature
component
NetCol500
-A060/
NetCol500
-A120 system 1/
32.9
32.9 + (L
– 10) x
0.21
32.9 + (L
– 10) x
0.28
NetCol8000
-
A090D
system 2
including a low
temperature
component
NetCol500
-A060/
NetCol500
-A120 system 2
32.9
32.9 + (L
– 10) x
0.21
32.9 + (L
– 10) x
0.28
NetCol8000
-
A055D
NetCol500
-A080
16.5
16.5 + (L
– 10) x
0.23
16.5 + (L
– 10) x
0.31
NetCol500
-A110
23
23 + (L
–
10) x 0.23
23 + (L
– 10) x
0.31
