Huawei NetCol500-A080 - Page 4

3
Refrigerant
pipes
L ≤ 60 m:
Gas pipe: outer diameter: 7/8 inch (22.22 mm); wall thickness: 1.2 mm;
operating pressure: > 4.5 MPa
Liquid pipe: outer diameter: 5/8 inch (15.88 mm); wall thickness: 1.0 mm;
operating pressure: > 4.5 MPa
60 m < L ≤ 100 m:
Gas pipe: outer diameter: 1 inch (25.4 mm); wall thickness: 1.2 mm; operating
pressure: > 4.5 MPa
Liquid pipe: outer diameter 3/4 inch (19.05 mm), wall thickness: 1.0 mm;
operating pressure: > 4.5 MPa
Thermal insulation foam: thickness ≥ 13 mm
Oil trap, inverted trap, and refrigerant pipe support
Recommended
cables
•
Power cable of NetCol8000-A045 indoor unit: 5 x 10 mm² (L1/L2/L3/N/PE)
•
Power cable of NetCol8000-A055 indoor unit: 5 x 10 mm² (L1/L2/L3/N/PE)
•
Power cable of NetCol8000-A060 indoor unit: 5 x 10 mm² (L1/L2/L3/N/PE)
•
Power cable of NetCol8000-
A090 indoor unit: 4 x 25 mm² (L1/L2/L3/N) + 16
mm² (PE)
•
Power cable of NetCol8000-
A120 indoor unit: 4 x 25 mm² (L1/L2/L3/N) + 16
mm² (PE)
•
Power cable of the air cooled outdoor unit: 4 x 25 mm² (L1/L2/L3/PE);
power cable of the water-cooled module: 3 x 1.5 mm² (L/N/PE)
•
(Optional) Signal cable of the indoor and outdoor units: 3 x 1.5 mm² (This
cable is required only for the outdoor unit configured with a temperature
control intelligent monitoring board, that is, the air cooled outdoor unit and
water-cooled module: 52273539, 52273541.)
•
Equipotential ground cable: 16 mm²
•
(Optional) T/H sensor cable, teamwork control and monitoring
communications cables: shielded network cable of Cat 5e or higher
specifications
(Optional)
Humidifier
water inlet
pipe
•
Rigid pipe connection: G 3/4 inch rigid pipe connector with internal threads,
rigid pipe (such as PP-R pipe)
•
Hose connection: G 3/4 inch pagoda connector with internal threads, hose
(such as EPDM pipe)
Drainpipe
•
Rigid pipe connection: G 3/4 inch rigid pipe connector with external threads,
rigid pipe (such as PP-R pipe)
•
Hose connection: G 3/4 inch pagoda connector with external threads, hose
(such as EPDM pipe)
•
Thermal insulation foam
Base
Indoor unit base (mandatory for the downflow model), outdoor unit support or
outdoor unit concrete base (depending on the scenario)
Low
temperature
component
cable
If a low temperature component is configured, an additional 2 x 1.5 mm
2
power
cable is required.
When the NetCol8000-A045/A055/A060 indoor unit is used,
prepare one group of outdoor unit cables for each indoor unit. (If
two indoor units are used, prepare two groups of outdoor unit
cables.) When the NetCol8000-A090/120 indoor unit is used,
prepare two groups of outdoor unit cables for each indoor unit.
