Huawei OptiX OSN 6800 - Optix OSN 8800 Subrack; Update Description

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
4 OptiX OSN 8800 Subrack
About This Chapter
4.1 Update Description
This section describes the hardware updates in V100R006C01 and later versions as well as
the reasons for the updates. Any product versions that are not listed in the document means
that they have no hardware updates.
4.2 OptiX OSN 8800 T64 Subrack
There are two types of OptiX OSN 8800 T64 subracks: enhanced and general.
4.3 OptiX OSN 8800 T32 Subrack
There are two types of OptiX OSN 8800 T32 subracks: enhanced and general.
4.4 OptiX OSN 8800 T16 Subrack
4.5 OptiX OSN 8800 Universal Platform Subrack
The OptiX OSN 8800 universal platform subrack can be installed in an N63B, N66B, or
19-inch cabinet. The subrack has 16 service slots.
4.1 Update Description
This section describes the hardware updates in V100R006C01 and later versions as well as
the reasons for the updates. Any product versions that are not listed in the document means
that they have no hardware updates.
Hardware Updates in V100R0010C00
Hardware Update
Reason for the Update
TN96EOW boards are added.
A TN96EOW board can be
inserted in slot IU22 of the
OptiX OSN 8800 T16 master
subrack.
TN96EOW boards are orderwire interface boards. Each
TN96EOW board provides eight E1 interfaces and one
orderwire interface and supports the processing of E1,
phone, and F1 services.
