7
3 OptiX OSN 8800 T32 Subrack
OSN 8800 T32
A subrack identified by "Enhanced" is an enhanced OptiX OSN 8800 T32 subrack. If the subrack is not
identified by "Enhanced", it is a general OptiX OSN 8800 T32.
NOTE
Board area
Fiber cabling area
Air filter
Fiber spool
Fan tray assembly
Mounting ear
Fan tray assembly
Item Specification
Dimensions 498 mm (W) x 295 mm (D) x 900 mm (H) (19.6 in. (W) x 11.6 in. (D) x 35.4 in. (H))
Weight (empty subrack
a
) 35 kg (77.1 lb.)
a: An empty subrack means no boards are installed in the board area, and no fan tray assembly or air filter is installed.
This end is secured to the subrack.
Mounting ear
for the left side
of the subrack
Mounting ear for
the right side of
the subrack
