APM30H
24
Installing the Power Cables for the IBBS200D/IBBS200T Battery Cabinet
c
Either IBBS200D or BBS200T is
used.
Installing the Power Cables for the Fan Assembly in the IBBS200D Battery Cabinet
d
APM30H
For details on how to make EPC4
connectors, see "Appendixes."
NOTE
NOTE
INPUT
Base
IBBS200D/T battery
cabinet
Base
IBBS200D battery
cabinet
