R207 Mobile WiFi V100R001
Product Description
Issue 02 (2014-04-21) Commercial in Confidence Page 10 of 19
Item Specifications
Maximum working time: 5–6 hours (depending on the network)
Maximum standby time: 300 hours (depending on the network)
External
interfaces
USB interface: Micro USB
SIM card interface: standard 6-pin SIM card interface
Indicators Signal Green: Strong signal
Orange: Weak signal
Red: No signal
Wi-Fi Green: Wi-Fi turned on
Battery Green: Sufficient battery
Blinking green: Charging the battery
Red: Low battery
SMS Green: New message
Blinking green: Inbox full
Power Blinks slowly: The Mobile WiFi enters the standby
mode
Button Power switch, Reset switch
Antenna
z
Built-in GSM/UMTS main diversity antenna
z
Built-in UMTS diversity antenna
z
Built-in WLAN antenna
Dimensions
(D × W × H)
60.0 mm×92.8 mm×14.0 mm
Weight about 74 g (including the battery)
Temperature
Operating: 0℃ to +35℃
Storage: -20℃ to +60℃
Humidity 5% to 95% ( non-condensing)
