Attribute Description
Maximum
transmission
distance
100 m
1000BASE-X port
When a 1000BASE-X port uses a GE optical module, it can only transmit and
receive data at 1000 Mbit/s and does not support the 100 Mbit/s transmission
speed. When a 1000BASE-X port uses a GE copper module, it can transmit and
receive data at 10 Mbit/s, 100 Mbit/s, or 1000 Mbit/s. Table 5-40 describes the
attributes of a 1000BASE-X port.
Table 5-40 Attributes of a 1000BASE-X port
Attribute Description
Connector type LC/PC
Optical port
attributes
Depend on the module used
Standards
compliance
IEEE802.3z
Console port
The console port is connected to a console for on-site conguration. Table 5-41
describes the attributes of the console port.
Table 5-41 Attributes of the console port
Attribute Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200
bit/s
Default value: 9600 bit/s
ETH management port
You can connect a switch to a conguration terminal or network management
workstation through the ETH management port to congure the switch locally or
