Huawei S1720 Series User Manual

No. Indicator Identifier Status Description
7 Service
interface
indicator
l GE
electrical
interfaces:
The first
indicator
shows the
status of
the bottom
left
interface.
The
indicators
correspond
to the
interfaces
from
bottom to
top and
from left to
right.
l GE optical
interfaces:
Each
optical
interface
has a
correspond
ing
indicator
above it.
Off
Green
Blinking green
The meanings of
service interface
indicators vary
according to the
indicator status. For
details, see Table
2-10.
8
Mini USB
indicator
The indicators
for the Mini
USB port and
CON port are
close to each
other. The
Mini USB
indicator has
an arrowhead
pointing to the
Mini USB
port.
Off
The Mini USB port is
not in use.
Green The Mini USB port is
in use.
9 CON
indicator
The indicators
for the Mini
USB port and
CON port are
close to each
other. The
CON indicator
Off
The Mini USB port is
in use.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 2 Product Hardware Introduction
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
21

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
