Huawei S1720 Series User Manual

No. Indicator Identifier Status Description
has an
arrowhead
pointing to the
CON port.
Green The Mini USB port is
not in use. This
indicator is steady
green unless the Mini
USB port is accessed.
Table 2-10 Description of service interface indicators in different modes
Display Mode Status Description
STAT Off The interface is not connected or
has been shut down.
Green The interface is connected.
Blinking green The interface is sending or
receiving data.
Speed Off The interface is not connected or
has been shut down.
Green 10M/100M/1000M interface: The
interface is operating at 10/100
Mbit/s.
1000M/10G interface: The
interface is operating at 1000
Mbit/s.
Blinking green
10M/100M/1000M interface: The
interface is operating at 1000
Mbit/s.
1000M/10G interface: The
interface is operating at 10 Gbit/s.
Stack Off The stack ID of the member
switch is not the number of the
interface in the off state.
Green The device is a not a command
switch:
l If the indicator of an interface
is steady on, the number of this
interface is the stack ID of the
device.
l If the first nine interface
indicators of the device are
steady on, the stack ID of the
device is 0.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 2 Product Hardware Introduction
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
22

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
