Table 2-4 Description of S3700-26C-HI indicators
No. Indicator Identifier Status Description
1 Power
indicator
PWR1 Off No power supply unit
is installed, or the
power supply is
abnormal when a
single power supply
unit is used.
Green The power supply is
normal.
Red
l Two power supply
units are installed
properly, but not
switched on.
l The power supply
units are switched
off.
l The power supply
units are faulty.
2
Power
indicator
PWR2 Off The power supply
units are not present,
or the power supply is
abnormal when a
single power supply
unit is used.
Green The power supply is
normal.
Red
l Two power supply
units are installed
properly, but not
switched on.
l The power supply
units are switched
off.
l The power supply
units are faulty.
3
System status
indicator
SYS Off The system is not
operating.
Green The system is not
operating properly or
is starting.
