Table 2-13 Description of S5710-28C-EI indicators
No. Indicator Identifier Status Description
1 From the rear
view: power
indicator on
the right
PWR1 Off The power supply
units are not present,
or the power supply is
abnormal when a
single power supply
unit is used.
Green The switch is
powered on.
Orange Possible causes are as
follows:
l Two power supply
units are installed,
but not switched
on.
l The power supply
units are not
connected
properly.
l A power supply
unit is faulty.
2
From the rear
view: power
indicator on
the left
PWR2 Off The power supply
units are not present,
or the power supply is
abnormal when a
single power supply
unit is used.
Green The switch is
powered on.
Orange Possible causes are as
follows:
l Two power supply
units are installed,
but not switched
on.
l The power supply
units are not
connected
properly.
l A power supply
unit is faulty.
3
System status
indicator
SYS Off The system is not
operating.
