No. Indicator Identifier Status Description
other. The
CON indicator
has an
arrowhead
pointing to the
CON port.
Green The Mini USB port is
not in use. This
indicator is steady
green unless the Mini
USB port is accessed.
11 ETH
indicator
The indicators
for the Mini
USB port,
CON port, and
ETH port are
close to each
other. The
ETH indicator
has an
arrowhead
pointing to the
ETH port.
Off
The interface is not
connected.
Green The interface is
connected.
Blinking green The interface is
sending or receiving
data.
Table 2-14 Description of service interface indicators in different modes
Display Mode
Status Description
STAT Off The interface is not connected or
has been shut down.
Green The interface is connected.
Blinking green The interface is sending or
receiving data.
Speed Off The interface is not connected or
has been shut down.
Green 10M/100M/1000M interface: The
interface is operating at 10/100
Mbit/s.
1000M/10G interface: The
interface is operating at 1000
Mbit/s.
Blinking green
10M/100M/1000M interface: The
interface is operating at 1000
Mbit/s.
1000M/10G interface: The
interface is operating at 10 Gbit/s.
