Table 2-15 Description of S5700-28C-PWR-EI indicators
No. Indicator Identifier Status Description
1 Power
indicator
PWR1 Off The power supply
units are not present,
or the power supply is
abnormal when a
single power supply
unit is used.
Green The power supply is
normal.
Red
l Two power
supply units are
installed properly,
but not switched
on.
l The power supply
units are switched
off.
l The card power
and PoE power
are abnormal.
Orange
If a single power
supply unit is
installed, the PoE
power is out of range.
If two power supply
units are installed, the
card power or PoE
power is out of range.
2
Power
indicator
PWR2 Off The power supply
units are not present,
or the power supply is
abnormal when a
single power supply
unit is used.
Green The power supply is
normal.
