No. Item Method
3 The installation holes on the support and
the expansion bolts adapt to each other
to ensure insulation between the support
and the ground and between the floor
bracket and the guide rail.
Use the multimeter to measure the
resistance between the bolt and the
ground bolt of the rack. The resistance
must be more than five mega ohms.
4 The surfaces of the cabinets in the same
row should be on the same plane. The
cabinets are arranged closely and tidily.
The cabinets on the sides of the main
path are aligned. The position error
should be less than 5 mm.
-
5 The accessories of the front and rear
doors are completely installed and the
connection board is installed for
combining cabinets.
-
6 The front door of a cabinet can be
opened and closed easily.
Open the door lock.
Close the door lock.
