Board Power Consumption Maximum Frame Size
H801SCUV
l Static: 89 W
l Maximum: 111 W (Fully
configured with 10GE service
board)
l Maximum: 134 W (Fully
configured with 20GE service
board)
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
Control board (MCU)
H801MCUD
l Static: 24 W
l Maximum: 26 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801MCUD1
l Static: 29 W
l Maximum: 33 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801MCUE
l Static: 24 W
l Maximum: 26 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
Upstream interface board (GIU)
H801GICD
l Static: 5.3 W
l Maximum: 5.3 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801GICE
l Static: 5.8 W
l Maximum: 11.8 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801GICF
l Static: 3.9 W
l Maximum: 3.9 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801GICG
l Static: 6.3 W
l Maximum: 9.2 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801GICK
l Static: 6.6 W
l Maximum: 7 W
2000 bytes
H802GICK
l Static: 7 W
l Maximum: 9 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801GSCA
l Static: 8 W
l Maximum: 10 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
171
