Huawei SmartAX MA5603T Hardware Description

Board Power Consumption Maximum Frame Size
H80DVCPE
l 17a:
– Static: 24 W
– Maximum: 64 W
l 8b:
– Static: 24 W
– Maximum: 70 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80DSDMM
l 17a:
– Static: 26 W
– Maximum: 59 W
l 8b:
– Static: 26 W
– Maximum: 58 W
l 35b:
– Static: 26 W
– Maximum: 64 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80DSDPM
l 17a:
– Static: 29 W
– Maximum: 73 W
l 8b:
– Static: 29 W
– Maximum: 72 W
l 35b:
– Static: 29 W
– Maximum: 78 W
l PTM: 2000 bytes
l ATM: 1800 bytes
Vectoring processing board
H806VPEA
l Static: 21 W (not configured with
service board)
l Maximum: 51 W (fully configured
with 6 VCMM boards in vectoring
mode)
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
181
