Huawei SUN2000-25KTL User Manual

5. To check the exact network status send the following message to mobile number of the device
SMS Command= *2222#<Stat.gsm>
IMEI
IMEI No. of the data logger (Device Key)
NW
Network
SIGN
Signal Strength out of 31
GPRS
CONT- connected , NC- not connected
PIP
Connected to TrackSo Server or not
CONT- connected, NC- not connected
LOG
no. of data points stored in devices incase of no interet
6. If the GSM light starts flashing 5 times then Login to www.trackso.in
with your Username/Password.
7. Click on ‘Units’ from the menu bar. You will be able to view your installed unit in the table as shown below.
8. Check if the Status becomes Receiveing for the relevant Unit.

Huawei SUN2000-25KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. input voltage	1100 V
MPPT operating voltage range	200 V - 1000 V
Max. input current per MPPT	26 A
Number of MPPTs	2
Rated AC output power	25000 W
Operating temperature range	-25°C to +60°C
Max. apparent AC power	27500 VA
Number of MPPT trackers	2
Protection degree	IP65
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Rated AC voltage	230 V / 400 V
Maximum Input Power	37500 W
Maximum Output Power	25000 W
Power Factor	0.8 leading ... 0.8 lagging
Communication	RS485
