Enclosure dimensions
Mounting bracket dimensions
2
Installation Requirements
Installation Angle
2.1
Installation Space
2.2
Vertical Backward HorizontalUpside down Forward
For ease of installing the SUN2000
on the mounting bracket,
connecting cables to the bottom of
the SUN2000, and maintaining the
SUN2000 in future, it is
recommended that the bottom
clearance be greater than or equal
to 600 mm and less than or equal
to 730 mm.
