Huawei UPS2000 - Page 29

UPS2000-(6 kVA-20 kVA)
Modbus Protocol Development Guide
2 Modbus Card Signal List
Issue 02 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
23
Signal
Namee
Parameter
Type
Gain
Unit or
Range
Register
Address
Address
Length
(Number
of Digits)
R/W
Attribute
segment 1
(16 bits)
hollow
01: solid
10: flow
to the
right
(bit 1, 0)
Energy flow
diagram
segment 2
Unsigned
short integer
(16 bits)
1
00:
hollow
01: solid
10: flow
to the
right
N9006
(bit 3, 2)
1
R
Energy flow
diagram
segment 3
Unsigned
short integer
(16 bits)
1
00:
hollow
01: solid
10: flow
to the
right
N9006
(bit 5, 4)
1
R
Energy flow
diagram
segment 4
Unsigned
short integer
(16 bits)
1
00:
hollow
01: solid
10: flow
downwa
rds
11: flow
upwards
N9006
(bit 7, 6)
1
R
Energy flow
diagram
segment 5
Unsigned
short integer
(16 bits)
1
00:
hollow
01: solid
10: flow
to the
right
N9006
(bit 9, 8)
1
R
Energy flow
diagram
segment 6
Unsigned
short integer
(16 bits)
1
00:
hollow
01: solid
10: flow
to the
right
N9006
(bit 11,
10)
1
R
Energy flow
diagram
segment 7
Unsigned
short integer
(16 bits)
1
00:
hollow
01: solid
10: flow
N9006
(bit 13,
12)
1
R
