Huawei WiFi Mesh 3 User Manual

12
• The gure is for reference only.
• Ensure that the HUAWEI CPE is connected to the Internet,
and the router is new or restored to factory settings.
• Ensure that the HUAWEI CPE supports the HUAWEI HiLink
function and CoAP protocol. Please consult the distributor for
details.
• Ensure that the distance between your router and the
HUAWEI CPE is less than 10 meters and there are no more
than one wall in between.
Step 2: When the indicator on the HUAWEI CPE starts to
ash, press the
H
button on it. Wait until the indicator on the
router shows that the router is connected to the network.
Step 3: Place the router in a room with weak signal strength
and connect the power supply.
Safety information
Operation and safety
• Do not use your device if using the device is prohibited. Do not
use the device if doing so causes danger or interference with other
electronic devices.
• Pacemaker manufacturers recommend that a minimum distance of
15 cm be maintained between a device and a pacemaker to prevent
potential interference with the pacemaker. If using a pacemaker,
hold the device on the side opposite the pacemaker and do not
carry the device in your front pocket.
• Avoid dusty, damp, or dirty environments. Avoid magnetic fields.
Using the device in these environments may result in circuit
malfunctions.
• Ideal operating temperatures are 0 °C to 40 °C. Ideal storage
temperatures are -40 °C to +70 °C. Extreme heat or cold may
damage your device or accessories.
• Keep the device and accessories in a well-ventilated and cool area
away from direct sunlight. Do not enclose or cover your device with
towels or other objects. Do not place the device in a container with
poor heat dissipation, such as a box or bag.
• The device should be installed and operated with a minimum
distance of 20 cm between the radiator and your body.

Huawei WiFi Mesh 3 Specifications

General

Antenna type	Internal
Product type	Mesh system
Product color	White
LED indicators	Yes
Maximum coverage	600 m²
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Flash memory	128 MB
Internal memory	256 MB
Number of products included	3 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Security algorithms	WPA3
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Ethernet LAN (RJ-45) ports	3
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12 W

Weight and Dimensions

Depth	107 mm
Width	70 mm
Height	174 mm
Weight	413 g
