Huawei WiFi Mesh 3 User Manual

11
You can connect your router in either of the following ways:
· Wired connection
Place your router in a room with weak or no signal strength,
then connect the WAN port of your router to the LAN port of
the HUAWEI CPE using an Ethernet cable.
· Wireless connection (using the H button)
Step 1: Place the router within one meter of the HUAWEI CPE
and connect the power supply.
6. How do I connect a Wi-Fi device to my router using WPS?
When your router is powered on, touch its
H
button, and then
press the
WPS
button on the Wi-Fi device (such as a phone)
within two minutes to initiate standard WPS negotiation and
connect the Wi-Fi device to the router's Wi-Fi network.
"HUAWEI router" refers to routers that support HarmonyOS
Mesh+. Please check if your device supports such features.
7. How do I use the NFC function of the router to quickly
connect to the Wi-Fi network?
8. How do I connect my router to the HUAWEI CPE to expand
the Wi-Fi network?
Unlock your phone, enable NFC on it, and touch the NFC
area on the back against the NFC area on the router, then
follow the onscreen instructions to connect the phone to the
Wi-Fi network.
This feature is available on Android devices that support NFC,
but some devices with non-standard NFC may be unable to
connect. iOS devices do not support connecting through NFC.
within one meter
wall in between the two routers.

Huawei WiFi Mesh 3 Specifications

General

Antenna type	Internal
Product type	Mesh system
Product color	White
LED indicators	Yes
Maximum coverage	600 m²
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Flash memory	128 MB
Internal memory	256 MB
Number of products included	3 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Security algorithms	WPA3
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Ethernet LAN (RJ-45) ports	3
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12 W

Weight and Dimensions

Depth	107 mm
Width	70 mm
Height	174 mm
Weight	413 g
