INSTALLATION WITHOUT TEMPERING VALVE
Piping to Hot
Water
Piping from
Cold Water
Air Gap
Drain Valve
Relief Valve
Discharge Pipe
Temperature & Pressure
Relief Valve
Support Bracket –
(bottom bracket
not shown)
Floor Drain
10
