INSTALLATION WITH TEMPERING VALVE
Piping to
Hot Water
Tempering
Valve
Support Bracket –
(bottom bracket not
shown)
Air Gap
Floor Drain
Relief Valve
Discharge Pipe
Temperature & Pressure
Relief Valve
Piping from
Cold Water
Drain Valve
