Hollow Shaft Absolute Encoder AMSH40
ASSH40
AMSH_ASSH_MANUAL-en_R2(2022-01-19)ID78121.docx
6 Dismantling
6.1 Safety instructions
Personnel
Dismantling must be carried out by skilled technical staff only.
WARNING!
Observe the safety instructions contained in Chapter 2 when dismantling the device!
NOTES!
Do not use a hammer or similar tool when installing the device due to the risk of damage
occurring to the bearings or coupling!
6.2 Dismantling the absolute encoder
To dismantling the absolute encoder follow the instructions given in chapters 5.5, and 5.7 in the
reverse order.
6.3 Connecting the encoder (electrically)
6.3.1 Connections
Cable glands are closed with a stopper to protect the devices on transport and storage.
Cable connections have to be executed according to the encoder type.
Connection diagrams have to be considered!
See connection diagram and in the terminal box.
Use of connection cables with diameter of min. 9 mm – max. 13 mm is essential to ensure the
protection class. Cable outlet should show preferably downwards.
Wiring arrangement and shielding:
(EMC measurement)
The cable shielding has to be connected on both ends!
The shield of the signal cable can be connected directly to the housing of the encoder by the cable
gland.
The common guidelines for EMC concerned cable routing have to be considered!
NOTES for UL and CSA!
Do only use copper cables
