18
Table 2 - Service Kit (P/N 2600KIT)
Part No. Description Quan.
500831 O-RING AS568-134 C366Y 70D 2
501125 BACK-UP RING S-11248-134 2
500780 O-RING AS568-014 C366Y 70D 1
506064 WIPER MICRODOT#959-10 1
505894 WIPER MICRODOT#959-7 1
506160 POLY-SEAL MICRODOT #125-00.875-2508 1
506158 POLY-SEAL MICRODOT #187-01.062-3128 1
122769 GLYD RING ASSEMBLY 1
Specifications for Standard Parts
1. All part numbers shown in this manual are available
from Huck. The 500000 series part numbers are standard
parts which can generally be purchased locally.
2. O-ring sizes are specified AS568 dash numbers (AS568 is
an Aerospace Size Standard for O-rings and formerly was
known as ARP). Table 2- Service Kit has specific material
and durometer just after the identifying AS568- dash numbers.
3. Back-up rings are W.S. Shamban & Co. series S-11248,
single turn TEFLON (MS-28774), or equivalent. The
dash numbers correspond to the O-ring dash numbers.
Conversion Kit, 123020
Conversion Kit, 123020, is supplied with each tool. Changing to kit’s older
heavier type hoses will then accommodate the following extension hose kits:
110838 12 ft.
110839 26 ft.
110840 38 ft.
110841 52 ft.
See appropriate section of DISASSEMBLY and ASSEMBLY- - CAUTION: Do
not use TEFLON tape on pipe threads - - see MAINTENANCE: General
Precautions.
123020 - Conversion Kit Includes:
110439 - Female Connector (1)
110438 - Male Connector (1)
503431 - Reducing Bushing (2)
110686 - Electric Male Connector (1)
505839 - Cable Tie (1)
