Huck 2600 - Sub-assembly Part Numbers and Notes

17
Sub-assembly Part Numbers and Notes
Refer to Illustrations
1 A matching 12 ft. Hose Kit, 122854, is available.
2 122767 - Front Gland Assembly includes:
122757 - Front Gland Housing
500831 - O-ring
501125 - back-up ring
506158 - POLY-SEAL
122758 - Front Wiper Housing
506064 - wiper
3 122760 - Piston Assembly includes:
(1) - Piston
122769 - GLYD RING Assembly
4 122768 - Rear Gland Assembly includes:
122761 - Rear Gland
500831 - O-ring
501125 - back-up ring
505894 - wiper
506160 - POLY-SEAL
122762 - Rear Gland Spacer
506159 - Retaining Ring
5 123338 - Trigger Cord Assembly includes:
120361 - Trigger Switch Assembly
505344 - Strain Relief
123337 - Trimmed Cord
506192 - Male Connector
6 CAUTION: Install cups of POLY-SEALS and wipers as
shown.
7 Torque screw, 505189, to 40 +/- 3 in. lbs.
8 Blind fasteners require pintail tube, 122771.
(1) Purchase sub-assembly when this part is required.
