Huffy 6V - Drive Battery Connection

11
Assembly
Connecting the Drive Battery to Drive Motor after Charging
Fuse box
white
Connector
white
motor connector
red
connector
red battery
connector
1. Plug the white motor connector into the white
Drive Switch connector as shown above.
2. Plug the red battery connector into the red
Drive Switch connector as shown above.
2
1
WARNING: Connect the red to red connectors, and white to
white connectors. Connecting incorrectly can damage the battery and/
or motor.
