Huffy 6V - Seat Installation

13
Tabs
2
1
1
2
2
1
1
1
1
B
A
Lock
Assembly
Installing the Seat
1. Align the Tabs (A) on the back of the seat with the slots in the back of the main
body.
2. Align the Lock on the front of the seat with the hole in the middle of the main
body hole. Be sure the lock is oriented so it will fi t into the slot.
3. Rotate and lower the seat onto the main body, Ensure the seat tabs stay in the
slots and the Lock (B) into the main body hole.
4. Using a coin or large screwdriver turn the Lock on the front of the seat to secure
the seat to the main body.
CAUTION: Ensure no wires or connectors are pinched under the seat.
Installation
