15
Maintenance
Charging the Drive Battery
Charging Port
Charger Port
22
Driving
control
board
1. Charge Drive Battery after 1-2 hours of use or when the vehicle does not move at its
normal speed.
2. Ensure Power Switch is OFF.
3. The Charging Port is located below the front edge of the seat bottom as shown.
4. First insert the Charger DC plug into the Charging Port and then insert the charger into
the wall socket.
5. After charging is complete (at least 8 hours, but not more than 15 hours) unplug the
Charger from the wall outlet.
6. Unplug the Charger from the Charging Port.
NOTE: The charger may feel warm during the charging. This is normal and not a cause for
concern. If excessively hot, unplug and replace.
NOTE: Before rst use, charge battery 10 to 12 hours.
WARNING: Risk of re. Do
not bypass or tamper.
