Hughes HX System User Manual

Appendix A • Technical specifications
1037852-0001 Revision A
79
HX150 satellite router
specifications
Listed below are technical specifications for the HX150 satellite
router.
Radio:
– 1 and 2 watt Ku-band
– 2 watt C-band
– 1, 2, and 3 1/2 watt Ka-band
HX50 Mechanical and Environmental Specifications
Weight (IDU): 4.8 lbs (2.18 kg)
Dimensions (IDU): 11.5" W x 1.8" H x 11" D
(29.21 cm W x 4.7 cm H x 27.94 cm D
Operating temperature:
– IDU: 0° C to +40° C°
– ODU: -30° C to +55° C
Input power: 90–264 VAC; 50–60 Hz
DC power supply (optional): 12–24 VDC
HX100 Mechanical and Environmental Specifications
1U enclosure for 19" rack
Weight (IDU): 5.5 lbs (2.5 kg)
Dimensions (IDU): 19" W x 1.75" H x 18" D
(48.26 cm W x 4.45 cm H x 45.72 cm D)
Operating temperature:
– IDU: 0° C to +50° C
– ODU: -30° C to +60° C
Input power: 90–264 VAC; 50–60 Hz
DC power supply (optional): 12–24 VDC
Input power: 90–264 VAC; 50–60 Hz
Satellite router(s) technical specifications (Continued)
HX150 Technical Specifications
Physical Interfaces
Two 10/100BaseT Ethernet LAN RJ45 ports
Two RS-232/RS-422 compatible serial ports
Satellite & Antenna Specifications
Outbound transmission format: DVB-S2
DVB-S2 supports adaptive coding and modulation
Information Rate (Receive or HX System Outbound Channel): up to
121 Mbps
Information Rate (Transmit or HX Inbound Channel): up to 3.2 Mbps
Symbol Rate (Receive): 1-45 Msps (in 1 Msps steps)
Symbol Rate (Transmit): 256, 512, 1024, 2048 ksps
Encoding DVB-S2 (Receive): Convolutional with concatenated Reed
Solomon; Viterbi 7/8, 5/6, 3/4, 2/3, or 1/2
